Ralli Wolf ARC250 (ECO250) ARC Series (Inverter)
Brand | Ralli Wolf |
|---|---|
Model | ARC250 (ECO250) |
Input Supply | 230V + 15%, 1Ph |
Rated Frequency (HZ) | 50 / 60 |
Rated Input Current (A) | 36 |
Rated Iput Power Capacity (KVA) | 8.3 |
No Load Voltage (V) | 66 |
Output Current Range (A) | 20 - 250 |
Rated Output Cycle (%) | 60 |
Power Factor | 0.93 |
Efficiency (%) | 85% |
Protection Class | IP21 |
Net Weight (Kg) | 6 |
Diamention (L x W x H) in mm (Approx) | 450 X 160 X 303 |
Invertor Technology | IGBT |
3 Mtrs Welding & Earthing Cable With Electrode Holder & Clamp.
Electrode 1.6 - 3.15 mm Continuous Use Electrode 4.00 mm - Intermittent Use.
Excellent Arc Strile With Inbuilt Arc Force & Hot Start.
Quick & Minimum Maintenance With Single PCB Design.
Applications : General Fabrication & Maintenance.
